24 Ports Unshielded Patch Panel (integrated)

Product application：

24 ports unshielded patch panel (integrated) is applied to management room, terminating the horizontal cable and switch devices, to achieve the purpose of information transmission.

Application standard：

ISO/IEC11801、 ANSI/TIA/EIA568C.2、YD/T 926.3

Product Features：

1. Modular design, 1U mode “4 in 1” PCB module installation, each module has 6 ports; 0.5 U mode “3 in 1” PCB module installation, each module group has 8 ports.
2. Each module installation group can be disassembled from the front of patch panel, which is convenient for management and maintenance.
3. The backside attached steel galvanized wire trimming frame, providing solid and stable space, it’s suitable for all kinds of installation method.
4. The marking system in front end is available, it is convenient for management and maintenance.
5. SECC or SPCC high quality steel material.
6. Gold plating on needle surface, strong anti-oxidation and stable transmission.
7. 180º and Dual Type routing way.
8. Cat.5e/Cat.6/Cat.6A series is provided, 0.5U and 1U specification and 19” rack mounting installed.
