12 Cores Bundle Fan-out Fiber Optical Pigtail

Product application：

12 Cores Bundle Fan-out Fiber Optical Pigtailis applied to connection between plug-in and adapter of integration disk mechanism and connection between tail and optical cable in ODF distribution box.

Application standard：

ISO/IEC 11801:2008、ANSI/TIA/EIA568-B 、YD/T1272

Product Features：

1. High-precision zirconium dioxide ceramic insert core, which has reliable performance.
2. It is used for in-rack connection, and the connection is simple, easy, convenient and economic.
3. Easy to install, small volume and large capacity
4. Low insertion loss and high reflection loss.
5. Optical fiber is protected by special bushing; therefore, the optical fiber can’t be twisted off or damaged and has good bending performance.
6. Connector can be matched with LC, FC, SC and ST, etc. and various length
can be provided according to customer requirements.
